_Note: This is an add-on to the Chapter "[Add Data and Data Dictionary](/data.qmd)". It describes how to (a) generate data dictionaries with R, and (b) how to create a machine readable documentation of the data._
## Automatic Generation of Data Dictionaries
First, we will demonstrate how to create a simple data dictionary
using the R package [`datawizard`][datawizard]. We will use the penguin data set which is introduced in the Chapter "[Add Data and Data Dictionary](/data.qmd)".
You can download it and put it into your project folder:
```{r}
#| include: false
invisible(loadNamespace("palmerpenguins")) # Tell renv that we need this package
stopifnot(packageDescription("palmerpenguins", fields = "License") == "CC0")
dat <- palmerpenguins::penguins
# Convert factors to integers
idx <- sapply(dat, is.factor)
dat[idx] <- lapply(dat[idx], as.integer)
dat[is.na(dat)] <- -99L
# Add extra column for training purposes
set.seed(1056517553L)
dat$cuteness <- sample.int(10, nrow(dat), replace = TRUE)
write.csv(
dat,
file = "data.csv",
row.names = FALSE
)
rm(idx, dat)
```
[data.csv](data.csv){.btn .btn-lg .btn-info download="data.csv"}
You can install the `datawizard` package into our `renv` environment using:
[datawizard]: https://easystats.github.io/datawizard/
```{.r filename="R Console"}
renv::install("datawizard")
```
We create a separate Quarto file for the data dictionary.
Create it by clicking on _File_ > _New File_ > _Quarto Document..._.
Choose a title such as `Data Dictionary`,
select _HTML_ as format,
uncheck the use of the visual markdown editor, and click on _Create_.
Remove everything except the YAML header (between the `---`).
To make the HTML file self-contained,
also set `embed-resources: true` such that the YAML header looks as follows:
```{.yml filename="data_dictionary.qmd"}
---
title: "Data Dictionary"
format:
html:
embed-resources: true
---
```
Then, save it as `data_dictionary.qmd` by clicking on _File_ > _Save_.
To create the actual data dictionary, first write a description for every column
so others can understand what the variable names mean.
Where necessary, also document their value
-- this is especially important if their meaning is non-obvious.
In the following, we demonstrate this by storing the penguins' binomial name
along with the English name.
``````{cat}
#| engine.opts: { file: "_data_dictionary.qmd" }
#| class.source: "md"
#| filename: "data_dictionary.qmd"
```{r}
#| echo: false
# Store the description of variables
vars <- c(
species = "an integer denoting penguin species",
island = "an integer denoting island in Palmer Archipelago, Antarctica",
bill_length_mm = "a number denoting bill length (millimeters)",
bill_depth_mm = "a number denoting bill depth (millimeters)",
flipper_length_mm = "an integer denoting flipper length (millimeters)",
body_mass_g = "an integer denoting body mass (grams)",
sex = "an integer denoting penguin sex",
year = "an integer denoting the study year"
)
# Store the description of variable values
vals <- list(
species = c(
"1" = "Adelie",
"2" = "Chinstrap",
"3" = "Gentoo"
),
island = c(
"1" = "Biscoe",
"2" = "Dream",
"3" = "Torgersen"
),
sex = c(
"1" = "female",
"2" = "male"
)
)
```
``````
Then, load the data and use `datawizard`
to add the descriptions to the `data.frame`:[^not-permanent]
[^not-permanent]: Note that the code provided does not alter the data file
-- no description will be added to `data.csv`.
The descriptions are only added to a (temporary) copy of the data set within R
to create the data dictionary.
::: {.column-margin}
{width=250px}
:::
``````{cat}
#| engine.opts: { file: "_data_dictionary.qmd", append: TRUE }
#| class.source: "md"
#| filename: "data_dictionary.qmd"
```{r}
#| echo: false
dat <- read.csv("data.csv")
dat[dat == -99L] <- NA
for (x in names(vars)) {
if (x %in% names(vals)) {
dat <- datawizard::assign_labels(
dat,
select = I(x),
variable = vars[[x]],
values = vals[[x]]
)
} else {
dat <- datawizard::assign_labels(
dat,
select = I(x),
variable = vars[[x]]
)
}
}
```
``````
Then, you can create the data dictionary containing the descriptions,
but also some other information about each variable
(e.g., the number of missing values) and print it.
``````{cat}
#| engine.opts: { file: "_data_dictionary.qmd", append: TRUE }
#| class.source: "md"
#| filename: "data_dictionary.qmd"
```{r}
#| echo: false
#| column: "body-outset"
#| classes: plain
#| tbl-cap: "{.borderless .hover}"
datawizard::data_codebook(dat) |>
datawizard::data_select(exclude = ID) |>
datawizard::data_filter(N != "") |>
datawizard::print_md()
```
``````
```{r}
#| child: "_data_dictionary.qmd"
```
Depending on the type of data, it may also be necessary
to describe sampling procedures (e.g., selection criteria),
measurement instruments (e.g., questionnaires),
appropriate weighting,
already applied preprocessing steps, or contact information.
In our case, as the data has already been published,
we only store a reference to its source.
The data set is from the R package `palmerpenguins`.
If you had it installed
you could use the function `citation()` to create such a reference:
```{r}
#| label: "data-citation"
#| eval: false
citation("palmerpenguins", auto = TRUE) |>
format(bibtex = FALSE, style = "text")
```
Without the package `palmerpenguins` installed,
you can find a [suggested citation on its website][palmerpenguins-citation]
and add that to your data dictionary:
[palmerpenguins-citation]: https://allisonhorst.github.io/palmerpenguins/#citation
```{r}
#| ref.label = "data-citation",
#| render = function(x, options) gsub("\\n", " ", x = x),
#| echo = FALSE,
#| class.output = "md code-overflow-wrap",
#| attr.output = 'filename="data_dictionary.qmd"'
# This chunk takes the output from the chunk "data-citation"
# and renders it with all newlines replaced by whitespaces.
```
Finally, you can render the data dictionary by running the following:
```{.bash filename="Terminal"}
quarto render data_dictionary.qmd
```
This should create the file `data_dictionary.html`
which you can open and view in your web browser.
If you want to learn more about the sharing of research data,
have a look at the tutorial "[FAIR research data management][fair-tutorial]".
[fair-tutorial]: https://lmu-osc.github.io/FAIR-Data-Management/
## Create Machine-Readable Variable Documentation
One could go even further by making the information machine-readable in a standardized way.
This section demonstrates how the title and description of the data set,
the description of the variables and their valid values are stored in a machine-readable way.
We'll reuse the descriptions we already created[^value-labels] and add a few others.
[^value-labels]: Unfortunately, the descriptions of values are not reused in this example,
as they are [not supported][enum-labels] by the specification we are using.
[enum-labels]: https://specs.frictionlessdata.io/patterns/#table-schema-enum-labels-and-ordering
First, store the title and description of the data set as a whole:
```{.r filename="R Console"}
table_info <- c(
title = "penguins data set",
description = "Size measurements for adult foraging penguins near Palmer Station, Antarctica"
)
```
As before, also provide a reference to the source.
```{r}
#| echo: false
#| class-output: "r code-overflow-wrap"
#| attr-output: 'filename="R Console"'
# We have provided the data set as CSV file to the readers.
# Therefore, we cannot assume or require that readers have
# the R package palmerpenguins installed. Instead, we create
# the citation on our end and hide how we obtained it.
citation("palmerpenguins", auto = TRUE)$url |>
paste0("dat_source <- \"", ... = _, "\"") |>
cat()
```
Next, create a list of the categorical variables' valid values:
```{.r filename="R Console"}
valid_vals <- list(
species = c("Adelie", "Gentoo", "Chinstrap"),
island = c("Torgersen", "Biscoe", "Dream"),
sex = c("male", "female"),
year = c(2007, 2008, 2009)
)
```
Finally, store the descriptions of the variables we already created earlier:
```{.r filename="R Console"}
# Store the description of variables
vars <- c(
species = "a character string denoting penguin species",
island = "a character string denoting island in Palmer Archipelago, Antarctica",
bill_length_mm = "a number denoting bill length (millimeters)",
bill_depth_mm = "a number denoting bill depth (millimeters)",
flipper_length_mm = "an integer denoting flipper length (millimeters)",
body_mass_g = "an integer denoting body mass (grams)",
sex = "a character string denoting penguin sex",
year = "an integer denoting the study year"
)
```
Generally, metadata are either stored embedded into the data or externally,
for example, in a separate file.
We will use the "[frictionless data](https://specs.frictionlessdata.io/)" standard,
where metadata are stored separately.
Alternatives would be [RO-Crate](https://www.researchobject.org/ro-crate/)
and [Psych-DS](https://psych-ds.github.io/).
Specifically, one can use the R package [`frictionless`][frictionless]
to create a _schema_ which describes the structure of the data.[^frictionless-note]
For the purpose of the following code,
it is just a nested list that we edit to include our own information.
We also explicitly record in the schema
that missing values are stored in the data file as `NA`
and that the data are licensed under CC0\ 1.0.
Finally, the package is used to create a metadata file that contains the schema.
[frictionless]: https://docs.ropensci.org/frictionless/
[^frictionless-note]: In June 2024, [version 2](https://datapackage.org/)
of the frictionless data standard has been released.
As of November 2024, the R package `frictionless` only supports the first version,
though support for v2 is [planned](https://github.com/frictionlessdata/frictionless-r/labels/datapackage%3Av2).
```{.r filename="R Console"}
# Install {frictionless} and the required dependency {stringi}
renv::install(c(
"frictionless",
"stringi"
))
# Read data and create schema
dat_filename <- "data.csv"
dat <- read.csv(dat_filename)
dat_schema <- frictionless::create_schema(dat)
# Add descriptions to the fields
dat_schema$fields <- lapply(dat_schema$fields, \(x) {
c(x, description = vars[[x$name]])
})
# Record valid values
dat_schema$fields <- lapply(dat_schema$fields, \(x) {
if (x[["name"]] %in% names(valid_vals)) {
modifyList(x, list(constraints = list(enum = valid_vals[[x$name]])))
} else {
x
}
})
# Define missing values
dat_schema$missingValues <- c("", "NA")
# Create package with license info and write it
dat_package <- frictionless::create_package() |>
frictionless::add_resource(
resource_name = "penguins",
data = dat_filename,
schema = dat_schema,
title = table_info[["title"]],
description = table_info[["description"]],
licenses = list(list(
name = "CC0-1.0",
path = "https://creativecommons.org/publicdomain/zero/1.0/",
title = "CC0 1.0 Universal"
)),
sources = list(list(
title = "CRAN",
path = dat_source
))
)
frictionless::write_package(dat_package, directory = ".")
```
This creates the metadata file `datapackage.json` in the current directory.
Make sure it is located in the same folder as `data.csv`,
as together they comprise a [data package](https://specs.frictionlessdata.io/data-package/).
